The EB18C-118LI is a robust, full lithium-ion powered straddle stacker built to handle intensive material handling with ease. Equipped with a high-capacity 24V/90Ah lithium battery, this unit supports up to 4,000 lb of lifting power and features a double mast design for extra lift stability. The advanced Curtis controller ensures smooth operation, while the 750W DC drive motor delivers reliable performance during long shifts. With a maximum lift height of 118″ (9.83′) and fork length of 45″, this stacker is ideal for high-bay storage and pallet stacking. Polyurethane wheels provide low-resistance movement and excellent floor protection. Weighing 2,270 lbs with a 63″ turning radius, it’s perfectly suited for tight spaces and high-demand workflows.
Full Powered Straddle Stacker EB18C-118LI, 4,000 lbs. Capacity
The EB18C-118LI is a fully lithium-powered straddle stacker with a 4,000 lb capacity, 118″ lift height, and 24V/90Ah battery. Designed with a double mast, Curtis controller, and durable poly wheels, it delivers powerful performance for heavy-duty warehouse tasks.
$12,158.00
Product Specifications
| Service Weight (lbs.) | 2270 lbs. |
|---|---|
| Load Capacity (lbs.) | 4000 lbs. |
| Max Lift Height (in.) | 118″ |
| Load Center (in.) | 24 |
| Fork Length (in.) | 45.3″ |
| Fork Width (in.) | 3.94″ |
| Lowered Height (in.) | 2.56″ |
| Adjustable Legs | 39.76-55.55″ |
| Turning Radius (in.) | 62.83″ |
| Extended Mast Height (in.) | 147.64″ |
| Lowered Mast Height (in.) | 79.33″ |
| Internal Charger | 24V/30A |
| Drive Motor | 750 Watt |
| Lift Motor | 3000 Watt |
| Battery | 24/90 Lithium |
| Brand | EKKO Lifts |
