Lithium Straddle Stacker EB14C-98LI, 3,000 lb. Capacity

The EKKO EB14C-98LI Straddle Stacker lifts up to 3,000 lbs. with lithium-ion power and a 98-inch lift height. It includes a Curtis controller, internal charger, and compact design for efficient indoor operation.

SKU: EB14C-98LI Categories: ,

$5,888.00

SlimCD Payment Icon Image

Product Specifications

Service Weight (lbs.) 1410 lbs.
Load Capacity (lbs.) 3000 lbs.
Max Lift Height (in.) 98″
Load Center (in.) 24
Fork Length (in.) 45.3″
Fork Width (in.) 4″
Fork Adjust Width (in.) 8.7-32.1″
Lowered Height (in.) 2.6″
Adjustable Legs 35.4-51.2″
Turning Radius (in.) 57.5″
Overall Length (in.) 73.7″
Overall Width (in.) 61″
Extended Mast Height (in.) 127.6″
Lowered Mast Height (in.) 75.2″
Internal Charger 24V/20A
Drive Motor DC Drive Motor
Lift Motor 2.2kW
Battery 24V/50Ah Lithium
Brand

The EKKO EB14C-98LI Full Lithium-Powered Straddle Stacker is a compact and efficient choice for light-duty lifting in space-constrained indoor environments. Powered by a 24V/50Ah lithium-ion battery with an internal charger and a 750W DC drive motor, it delivers quick charging, low maintenance, and dependable performance. With a 3,000 lb. lifting capacity, 45-inch forks, a 75.2-inch lowered mast, and a maximum lift height of 98 inches, this unit is ideal for retail, warehouse, and stockroom applications.

The Curtis controller ensures precise control, while the straddle leg design offers stability when handling standard pallets. Poly tires and a 1,410 lb. frame provide smooth movement across clean, level surfaces.
