Diesel Forklift With Solid Pneumatic Tires EK25D, 5,000 lbs. Capacity

The EKKO EK25D Diesel Forklift lifts up to 5,000 lbs. with solid pneumatic tires and a Mitsubishi 4EG engine. It features side shift, tilt, and 4-way valves for smooth and controlled performance in tough environments.

SKU: EK25D Category:

$34,999.00

SlimCD Payment Icon Image

Product Specifications

Drive Type Diesel
Load Capacity (lbs.) 5000 lbs.
Load Center (in.) 24
Max Lift Height (in.) 185
Wheelbase (in.) 62.9″
Service Weight (lbs.) 8465 lbs.
Tire Material Solid Pneumatic Tire
Overall Width (in.) 45.2″
Overall Length W/ Forks (in.) 144.6″
Overall Length W/O Forks (in.) 99.6″
Travel Speed (mph) 10.6/11.8 (mph)
Free Lift Height (in.) 43.7″
Fork Size (in.) 42.1″ x 4.8″ x 1.5″
Battery 12/80, V/Ah
Engine Mode Mitsubishi 4EG
Engine Rated Power Deisel 49/2250, HP/rpm
Brand

The EKKO EK25D Diesel Forklift is a rugged solution for heavy-duty lifting in outdoor or rough-terrain environments. Powered by a Mitsubishi 4EG diesel engine and equipped with solid pneumatic tires, it delivers strong traction and dependable performance. With a 5,000 lb. lifting capacity, 42-inch forks, an 83-inch lowered mast height, and a maximum lift height of 185 inches, this forklift is built for productivity and versatility.

Standard features include side shift, free lift, tilt, and 4-way hydraulic valves, giving operators precise control and efficient handling. At 8,465 lbs., it offers a stable platform for safe and consistent lifting across a wide range of industrial applications.
