Vestil EPT-2796-45-AGM Steel Electric Pallet Jack

The Vestil EPT-2796-45-AGM Steel Electric Pallet Jack has an easy and quick operation. The unit raises and lowers loads with a push of a button. It can maneuver loads in warehouses and trailers. The reinforced welded forks have adjustable tie-rods that provide long service. The high-torque DC drive and lift motors handle heavy-duty jobs. Unit includes integral battery charger, battery level gauge, and emergency battery disconnect. The truck rolls smoothly on poly-on-steel, steer and load wheels. Ergonomic handle features easy to operate throttle with infinite adjustment of forward and reverse speeds, lift/lower controls, proprietary safety-enhancing emergency reverse function, and horn.

SKU: EPT-2796-45-AGM Categories: ,

$12,590.82

Material Handling Small Logo
SlimCD Payment Icon Image

Product Specifications

Weight 1442 lbs
Shipping Dimensions 125 × 30 × 51 in
Lead Time

6 Days

Lead Time Tier 1

6 Days

Lead Time Tier 2

12 Days

Lead Time Tier 3

20 Days

Quantity Tier 1

1-1

Quantity Tier 2

2-3

Quantity Tier 3

4-

Uniform Capacity Lb

4500

Overall fork width in

27

Overall fork length in

96

Lowered height in

3.2

Raised height in

8.2

Battery type

(4) AGM

Dc motor voltage

24

Battery charger

120v Input, 24v/20 Amp

Turn radius in

52

Drive kw

1.2

Lift motor kw

2.0

Drive wheel diameter in

10

Drive wheel width in

3-1/8

Load roller diameter in

2-3/4

Load roller width in

3

Stabilizing roller width in

3

Wheel roller type

Poly On Steel

Individual fork width in

6-7/8

Rider platform length in

12

Rider platform width in

18

Rider platform height in

4-3/4

The Vestil EPT-2796-45-AGM Steel Electric Pallet Jack has an easy and quick operation. The unit raises and lowers loads with a push of a button. It can maneuver loads in warehouses and trailers. The reinforced welded forks have adjustable tie-rods that provide long service. The high-torque DC drive and lift motors handle heavy-duty jobs. Unit includes integral battery charger, battery level gauge, and emergency battery disconnect. The truck rolls smoothly on poly-on-steel, steer and load wheels. Ergonomic handle features easy to operate throttle with infinite adjustment of forward and reverse speeds, lift/lower controls, proprietary safety-enhancing emergency reverse function, and horn. When the Proprietary Safety-enhancing Emergency Reverse function is actuated, the emergency reverse belly switch instantly reverses direction and moves the unit forward (away from the operator) until the switch is released or after 1.5 seconds have elapsed. The built-in safety circuit will automatically disable the entire unit if the emergency reverse belly switch is activated for more than 1.5 seconds after which the unit must be re-set to return to normal operating conditions. This state-of-the-art safety device provides a high degree of operator protection. Includes an electromagnetic disc brake with automatic dead-man feature that activates when the user releases the handle. Also includes a stand-on platform, which flips up when not in use.

  • Fully-powered pallet truck makes movement of pallets quick and easy
  • Includes fingertip RAISE and LOWER buttons for operator convenience
  • Safety belly reverse button improves worker safety
  • Easy-to-operate throttle for forward and reverse direction
