Vestil EHLT-N-1648-2-32 ELECTRIC HYDRAULIC NARROW LIFT 2K

Vestil Item #EHLT-N-1648-2-32 · MFR #EHLT-N-1648-2-32
Quick Answer: The Vestil EHLT-N-1648-2-32 ELECTRIC HYDRAULIC NARROW LIFT 2K is a lift table with 2000 load capacity and 32 raised height. Priced at $4,148.14, in stock with factory-direct shipping.
  • The Vestil EHLT-N-1648-2-32 is used by all types of manufacturing and warehouse facilities.
Brand
Vestil
Condition
New
Weight
300 lb
Dimensions
48.375″L × 16.375″W × 8″H
Category
Lift Tables
🚚 Factory-Direct Shipping 🏷️ Volume Pricing Available 🛠️ Expert Support: (847) 278-2311 Sales & expertise backed by Premier Handling Solutions, Inc.

Product Details

The Electric Hydraulic Scissor Lift Table is used by all types of manufacturing and warehouse facilities. Safety features include: electric toe guard to protect pinch points while lowering of the table, internal safety velocity fuse to maintain platform height in an event of hose or fitting failure, maintenance prop, upper travel limit switch to stop table at maximum height, and a displacement-style hydraulic cylinders for maximum strength. It also features a pressure plated pump, manifold system, displacement style hydraulic cylinder, and a state-of-the-art lifetime lubricated bearings. The standard 56 frame electric motor is a fully enclosed with optional voltages available.

  • Electric toe guard protects pinch points while lowering for max. safety
  • Internal safety velocity fuse maintains platform height in case of hose or fitting failure
  • Displacement-style hydraulic cylinders for maximum strength
  • Standard 56 frame electric motor is a fully enclosed with optional voltages available

Specifications

Item NumberEHLT-N-1648-2-32
Manufacturer Part #EHLT-N-1648-2-32
Brand Vestil
Weight300 lb
Dimensions (L×W×H)48.375″ × 16.375″ × 8″
Lead Time60 days for 1–2 units · call for 3+ units
Load Capacity (lbs.)2000
Raised Height (in.)32
Lowered Height (in.)8
Voltage/Phase460/3
Hertz60
Motor Horsepower2
Hydraulic Component (psi)3000
Cord Length (in.)96
Push Button Control24V AC
Power TypeElectric
Capacity (lbs)2000
MaterialSteel
ColorBlue
Freight Class92.5
Country of OriginUS
Warranty1 Year (Limited - Parts)
